Our explosion-safe window air conditioners are made to safely provide a pleasant climate in an area that can contain an explosive atmosphere as a result of released gas.

The Artidor AR-054 air conditioners are explosion-safe and certified in accordance with the European ATEX Directive 2014/34/EU (ATEX 114) and they are CE marked.

No connections need to be made to the cooling system to install the compact window air conditioner and therefore there is no need to call in a specialized refrigeration technician. The mechanical and electrical installation of the unit is also extremely simple and can be accomplished quickly and efficiently.

Due to the use of DC inverter technology, the window air conditioners meet the strict Ecodesign requirements laid down in the European directive 2009/125/EC. The offered solution is not only safe but also energy efficient.

The window air conditioners comply with the requirements for product category 3 G and are suitable for use in Zone 2.

Features

•Capacities up to 14 kW
•Suitable for hazardous environments in which gas, vapor or mist is present, classified as Zone 1
•ATEX EU Type Examination Certificate
•Robust axial fan with aluminium impeller
•Intrinsically safe room air thermostat
•For ambient temperatures up to 55 °C
•Refrigerant R513A
•Increased safe junction box for easy installation
•230 VAC, 50 / 60 Hz

Technical Properties

• Nominal capacity: 2 up to 14 kW
• Explosion safety: II 2 G Ex db eb h ia IIC T4 Gb
• Conformity: European directive 2014/34/EU (ATEX 114)
• Applied standards: EN 60079-0:2012 / A11:2013, EN 60079-1:2014, EN 60079-7:2015 / A1:2018, EN 60079-11:2012, EN 80079-36:2016 and EN 80079-37:2016
• Certificate: EU Type Examination Certificate No. KIWA 19ATEX0049X
• Ambient temperature: -20 °C up to +55 °C
• Fan(s): 230 VAC, 50 / 60 Hz single phase or 400 VAC, 50 / 60 Hz three phase Diameter(s): 250, 300, 350, 400, 450 or 500 mm
• No. of fans: Up to 3
• Fan properties: Short cased 4-pole axial fan with aluminium impellor
• Power supply: 220 – 240 VAC, 50 Hz (400 VAC, 3 phase, 50 Hz on request)
• Fin spacing: 4 or 6 mm
• Electric heating: Not available
• Refrigerant: R513A
